XPARTCO 5303918214 Refrigerator Defrost Thermostat AP2150145, PS469522
XPARTCO 5303918214 Refrigerator Defrost Thermostat AP2150145, PS469522
Couldn't load pickup availability
XPARTCO 5303918214 Refrigerator Defrost Thermostat
Clip-on defrost bi-metal thermostat for select Frigidaire-built refrigerators and freezers.
Product Overview
The XPARTCO 5303918214 Refrigerator Defrost Thermostat monitors evaporator temperature as part of the automatic defrost circuit. During the defrost cycle, the thermostat helps control power to the defrost heater so frost can be removed from the evaporator while protecting the system from excessive heat.
This is a quality XPARTCO aftermarket replacement part designed for compatible Frigidaire-built refrigerators, including select Frigidaire, Kenmore, Crosley, Gibson, Tappan, Kelvinator, and White-Westinghouse models.
Quick Answer
5303918214 is a clip-on refrigerator defrost thermostat identified by the L47-22F temperature code. It cross-references to AP2150145, PS469522, 892545, and related Frigidaire/Electrolux catalog numbers and is used in the evaporator defrost circuit on compatible refrigerators. Always verify the complete appliance model number before ordering.
Common Problems This Part May Fix
- Heavy frost or ice buildup on the evaporator
- Freezer is cold but fresh-food section is too warm
- Refrigerator does not defrost automatically
- Airflow is restricted by an iced evaporator coil
- Defrost heater does not energize when the thermostat should be closed
- Temperature rises because frost blocks evaporator airflow
Replaces and Cross-References
Cross-reference numbers are provided for identification. XPARTCO is an aftermarket replacement brand and is not manufactured by Frigidaire or Electrolux.
Compatibility
Used on select refrigerators and freezers manufactured by Electrolux/Frigidaire and sold under several brand names. Confirmed model examples include:
Important: This is only a partial compatibility list. Verify the complete model number from the refrigerator identification label before purchasing.
Key Features
- Quality XPARTCO aftermarket replacement
- Defrost bi-metal thermostat / defrost limit thermostat
- Temperature code: L47-22F
- Clips to evaporator tubing on compatible models
- Two-wire electrical connection
- Helps control the automatic defrost heater circuit
- Designed for select Frigidaire-built refrigerators and freezers
Product Specifications
| XPARTCO Part Number | 5303918214 |
| Brand | XPARTCO |
| Part Type | Refrigerator Defrost Thermostat |
| Thermostat Style | Clip-On Bi-Metal / Defrost Limit |
| Temperature Code | L47-22F |
| Thermostat Function | Evaporator Defrost Limit / Bi-Metal |
| Wire Connection | Two-Wire |
| Mounting | Evaporator Tube Clip |
| Condition | New |
| Part Quality | Aftermarket Replacement |
| Application | Refrigerator / Freezer Defrost Circuit |
Installation Notes
- Unplug the refrigerator or disconnect power at the circuit breaker before service.
- Remove freezer shelves, bins, and the rear evaporator cover as required by the appliance design.
- Allow heavy ice buildup to thaw safely; do not use sharp tools that can puncture the evaporator.
- Locate the thermostat clipped to the evaporator tubing and photograph the original wire routing.
- Disconnect or cut the old thermostat leads only as directed by the appliance service procedure.
- Install the new thermostat in the same location and orientation on the evaporator tubing.
- Use properly rated sealed connectors or heat-shrink splices suitable for the cold, damp freezer environment.
- Keep wiring clear of the evaporator fan, heater, sharp sheet metal, and moving components.
- Reassemble all covers before restoring power.
Diagnostic note: Frost buildup can also be caused by a failed defrost heater, defrost timer/control board, wiring fault, door-seal problem, or airflow issue. Test the defrost system before replacing parts whenever possible.
Frequently Asked Questions
What does this thermostat do?
It senses evaporator temperature and works with the refrigerator's defrost system to control the defrost-heater circuit.
Is this a Genuine Frigidaire OEM part?
No. This is a quality XPARTCO aftermarket replacement for compatible Frigidaire-built appliances.
Does this replace AP2150145 / PS469522?
Yes. AP2150145 and PS469522 are established cross-reference numbers for 5303918214.
What does L47-22F mean?
L47-22F is the thermostat's temperature code used to identify the correct defrost thermostat specification. Match this code or the confirmed appliance part number when replacing the thermostat.
Will this fit every Frigidaire refrigerator?
No. Frigidaire has used multiple defrost thermostat designs. Verify your complete model number and original part number before ordering.
Shop With Confidence
Verify the refrigerator model, original thermostat number, mounting style, and wire configuration before ordering. Compatibility support is available to help confirm fitment.
